LIGHTING
Fault finding – Fault Finding Chart
80D
UCH
Vdiag No.: 09
ALP 5 No front fog lights
NOTES
Only consult this customer complaint after a full check with the diagnostic tool.
There must be no present or stored faults.
Check the conformity of status ET324 Side lights request.
If not correct, refer to the interpretation of this status.
Special note:
Use the Wiring Diagrams Technical Note for DUSTER.
Check the condition of the bulbs. Replace the bulbs if they are defective (see MR 451 Mechanical, 80B, Front
headlight, Front fog light bulb: Removal - Refitting).
Check the presence and condition of the front fog light relay (component code 231) and fuse F31 (15 A).
Replace the relay and the fuse if the check is not correct.
Check the condition and connection of the connectors of the front fog light relay, component code 231, the front
right-hand fog light, component code 176, the front left-hand fog light, component code 177, and the lighting stalk,
component code 209,
If the connector is faulty and there is a repair procedure (see Technical Note 6015A (Renault) or Technical Note
9804A (Dacia), Electrical wiring repair, Wiring: Precautions for repair), repair the connector, otherwise replace
the wiring.
Check for +12 V (when the front fog lights are requested) on the following connection:
• 8FB of components 176 and 177,
Check for earth on the following connection:
• MB of components 176 and 177,
If the connections are faulty and if there is a repair procedure (see Technical Note 6015A (Renault) or Technical
Note 9804A (Dacia), Electrical wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise
replace it.
UCH_V09_ALP5
