80D-46
AFTER REPAIR Check the system operation.
V1
MR-453-X79-80D000$120.mif
LIGHTING
Fault finding – Fault Finding Chart
80D
UCH
Vdiag No.: 09
ALP 7
CONTINUED
Check for earth on the passenger glovebox switch, component code 161 on the following connection:
• MAN of component 161.
If the connection is faulty and there is a repair procedure (see Technical Note 6015A, Electrical wiring repair,
Wiring: Precautions for repair), repair the wiring, otherwise replace it.
Check the continuity and insulation of the following connection:
• 17A between components 168 and 161,
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
Check for correct operation of the passenger glovebox switch, component code 161.
Check the continuity between connections 17A and MAN of the passenger glovebox switch. If not correct, ensure
the conformity of the switch.
If the fault is still present, contact the Techline.
