80D-58
AFTER REPAIR Check the system operation.
V1
MR-453-X79-80D000$120.mif
LIGHTING
Fault finding – Fault Finding Chart
80D
UCH
Vdiag No.: 09
ALP 13
The backlighting of the hazard warning lights control button
operates erratically
NOTES
Only address this customer complaint after a complete check with the diagnostic
tool.
There must be no present or stored faults.
Check the conformity of status ET324 Side lights request and ET485 Hazard warning
lights signal.
If not correct, refer to the interpretation of this status.
Special note:
Use the Wiring Diagrams Technical Note for DUSTER.
Put the lighting stalk, component code 209 in the side lights position.
Check the condition and connection of the hazard warning lights control connector, component code 125.
If the connector is faulty and there is a repair procedure (see Technical Note 6015A (Renault) or Technical Note
9804A (Dacia), Electrical wiring repair, Wiring: Precautions for repair), repair the connector, otherwise replace
the wiring.
Check for +12 V (when side lights are requested) on the following connections:
• LPG of component 125,
Check for earth on the following connection:
• MAN of component 125,
If the connections are faulty and if there is a repair procedure (see Technical Note 6015A (Renault) or Technical
Note 9804A (Dacia), Electrical wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise
replace it.
UCH_V09_ALP13
