82D-21
V1
MR-453-X79-82D000$080.mif
ACCESS – SAFETY
Fault finding – Interpretation of faults
82D
UCH
Vdiag No.: 09
DF272
PRESENT
OR
STORED
CODED LINE CIRCUIT
CC.0: Short circuit to earth
CC.1: Short circuit to + 12 V
NOTES
Special note:
Use the Wiring Diagrams Technical Note for DUSTER.
Check the connection and condition of the injection computer connector, component code 120.
If the connector is faulty and if there is a repair procedure (see Technical Note 6015A (Renault) or Technical
Note 9804A (Dacia), Electrical wiring repair, Wiring: Precautions for repair), repair the connector, otherwise
replace the wiring.
Check the connection and condition of the UCH connector, component code 645.
If the connector is faulty and if there is a repair procedure (see Technical Note 6015A (Renault) or Technical
Note 9804A (Dacia), Electrical wiring repair, Wiring: Precautions for repair), repair the connector, otherwise
replace the wiring.
Check the continuity and insulation of the following connection:
• H17 between components 645 and 120.
If the connection is faulty and if there is a repair procedure (see Technical Note 6015A (Renault) or Technical
Note 9804A (Dacia), Electrical wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise
replace it.
If the fault is still present, contact the Techline.
UCH_V09_DF272
AFTER REPAIR
Deal with any other faults.
Clear the stored faults.
