12B-7
TURBOCHARGING
Turbocharger oil pipe: Removal - Refitting
K9K
12B
a Extract the turbocharger oil return pipe from the cyl-
inder block.
a Remove the turbocharger oil return pipe seals.
REFITTING THE TURBOCHARGER OIL
RETURN PIPE
I - REFITTING PREPARATION OPERATION
a parts always to be replaced: turbocharger oil
pipe seal.
a Use SURFACE CLEANER (see Vehicle: Towing
and lifting) (04B, Consumables - Products) to clean
and degrease:
-the seal housing on the turbocharger oil return pipe
if it is to be reused,
-the turbocharger oil return pipe joint face if it is to
be reused,
-the turbocharger oil return pipe joint face on the tur-
bocharger,
-the turbocharger oil return pipe housing in the cylin-
der block.
a Lubricate the turbocharger oil return pipe O-ring with
clean engine oil.
II - REFITTING OPERATION
a Proceed in the reverse order to removal.
a Torque tighten the turbocharger oil return pipe
bolts (12 N.m).
WARNING
To ensure proper sealing, the gasket surfaces
must be clean, dry and not greasy (avoid any fin-
ger marks).
