13A-4
FUEL SUPPLY
Manual priming pump: Removal - Refitting
K9K
13A
II - OPERATION FOR REMOVAL OF PART
CONCERNED
a Disconnect the fuel supply pipe at the fuel tank end
at (3) .
a Insert the blanking plugs.
a Unclip the fuel supply pipe under the body at (4) .
a Disconnect the connection (5) from the fuel supply
pipe on the fuel filter.
a Unclip the fuel supply pipe at (6) .
a Remove the fuel supply pipe through the engine
compartment.
REFITTING
I - REFITTING OPERATION FOR PART
CONCERNED
a Proceed in the reverse order to removal.
a Ensure that the fuel supply pipe unions are clicked
into position properly.
II - FINAL OPERATION
a Prime the fuel circuit using the priming pump.
146375
146376
WARNING
Check that there are no leaks:
-run the engine at idle speed for 2 minutes,
- accelerate several times at no load,
- switch off the ignition,
- check that there is no fuel escaping.
