19A-10
COOLING
Cooling radiator: Removal - Refitting
K4M
19A
a Remove the condenser bolts (2) .
a Remove the cooling radiator hose clips (3) using the
tool (Mot. 1448).
a Disconnect the cooling radiator hoses using the
(Car. 1363).
a Remove the engine cooling radiator from above the
vehicle.
REFITTING
I - REFITTING PREPARATION OPERATION
a Always replace the cooling radiator hose clips.
II - REFITTING OPERATION
a Proceed in the reverse order to removal.
a Refill and bleed the cooling system (see 19A, Cool-
ing, Cooling system: Draining - Refilling, page
19A-6) .
a Connect the battery (see Battery: Removal - Refit-
ting) (80A, Battery).
145080
145560
