19B-11
EXHAUST
Catalytic converter: Removal - Refitting
K9K, and 796
19B
a Remove the bolt from the downstream strut on the
catalytic converter (2) .
a Loosen the downstream strut bolt and nut on the
gearbox (3) .
a Remove the downstream strut.
a Remove:
-the bolts of the upstream strut (4) ,
-the upstream strut.
a Remove the catalytic converter nuts on the turbo-
charger (5) .
a Remove:
- the catalytic converter (6) ,
-the seal between the turbocharger and the catalytic
converter,
- the exhaust flange sealing ring.
144536
144537
145311
144820
