19C-2
TANK
Fuel tank: Draining
19C
a Remove:
-the front right-hand wheel arch liner bolts (4) ,
-the clip of the wheel arch liner (5) ,
-the diesel filter protector (see ) .
a Disconnect the fuel outlet pipe from the fuel filter.
a Connect a pneumatic transfer pump for fuels to
the fuel filter.
a Prepare for fuel outflow.
a Drain the fuel tank.
REFITTING
a Proceed in the reverse order to removal.
144823
144827
