21A-3
MANUAL GEARBOX
Differential output seal: Removal - Refitting
JR5
21A
II - REFITTING OPERATION
a Refit the differential output seal using the tool (1)
with A on the right-hand side, and B on the left-hand
side.
a Tap the toolwith a copper hammer (2) to fit the new
differential output seal fully.
III - FINAL OPERATION
a Proceed in the reverse order to removal.
a Top up the gearbox (see 21A, Manual gearbox,
Manual gearbox oils: Draining - Filling, page
21A-1) .
109407
