31A-8
FRONT AXLE COMPONENTS
Front brake calliper: Removal - Refitting
31A
a Always replace the guide pin bolts each time they
are removed.
II - REFITTING OPERATION
a Without using a tool, screw the calliper to the brake
hose as tightly as possible.
a Refit the guide pin upper bolt.
a Torque tighten the guide pin upper bolt (34 N.m).
a Refit the brake pads (see 31A, Front axle compo-
nents, Front brake pads: Removal - Refitting,
page 31A-3) .
a Torque tighten the brake hose on the calliper (17
N.m).
III - FINAL OPERATION
a Remove the tool pedal press.
a Bleed the brake circuit (see 30A, General informa-
tion, Braking circuit: Bleed, page 30A-4) .
a Refit the front wheel on the side concerned (see
35A, Wheels and tyres, Wheel: Removal - Refit-
ting, page 35A-1) .
IMPORTANT
To avoid any accident, bring the pistons, brake
pads and brake discs into contact by depressing
the brake pad several times.
