31A-28
FRONT AXLE COMPONENTS
Front driveshaft hub carrier: Removal - Refitting
31A
a Remove the front brake calliper mounting bolts (1) .
a Suspend the « calliper - front brake calliper
mounting » assembly on the suspension spring.
a Remove:
- the hub nut (4) using the,
- the front brake disc (see 31A, Front axle compo-
nents, Front brake disc: Removal - Refitting,
page 31A-15) .
a Remove the front brake disc protector (see 31A,
Front axle components, Front brake disc protec-
tor: Removal - Refitting, page 31A-13) .
a Remove:
- the track rod end nut (3) ,
- the nut or bolt of the lower ball joint,
- the shock absorber base bolts (2) .
108350
108921
WARNING
In order to prevent irreversible damage to the
front hub bearing:
- Do not loosen or tighten the driveshaft nut when
the wheels are on the ground.
- Do not place the vehicle with its wheels on the
ground when the driveshaft has been loosened
or removed.
WHEEL DISC PROTECTOR
