31A-32
FRONT AXLE COMPONENTS
Front hub carrier bearing: Removal - Refitting
31A
II - REFITTING OPERATION
a
a Position the sensor target on the bearing towards
the vehicle interior.
a Apply pressure to the external bush with a tube with
an external diameter of 80 mm and an internal diam-
eter of 75 mm (old bearing).
a Apply a fitting force of 50,000 N to ensure that the
bearing is correctly fitted on the hub carrier shoulder.
a Refit:
- the hub using a tube with an external diameter of
55 mm,
- the elastic ring on the front driveshaft hub carrier.
III - FINAL OPERATION
a Proceed in the reverse order to removal.
141795
115568
WARNING
To ensure that the wheel speed sensor works
properly, do not mark the sensor target (3) on the
bearing.
20789
IMPORTANT
To avoid any accident, bring the pistons, brake
pads and brake discs into contact by depressing
the brake pad several times.
