37A-28
MECHANICAL COMPONENT CONTROLS
Brake pedal switch: Removal - Refitting
37A
a
a Carefully support the return of the brake pedal (shim
in place).
a Connect the brake light switch connector.
III - FINAL OPERATION
a Check that the brake light switch is operating cor-
rectly:
-depress the brake pedal to switch on the lights,
-release the brake pedal to switch off the lights.
a Refit the dashboard lower trim (depending on the
equipment level).
136037
Note:
To adjust the position of the piston of the brake
light switch, place a 2 mm thick shim (4) between
the piston crown of the brake light switch and the
brake pedal.
Note:
The brake light switch has an automatic adjust-
ment feature which adapts to the position of the
pedal.
The automatic adjustment makes a clicking noise
when in operation.
