10A
-
36
ENGINE AND CYLINDER BLOCK ASSEMBLY
Oil filter: Removal - Refitting
K4M
10A
a
Top up the engine oil level to the dipstick if neces-
sary (see
10A
,
Engine and cylinder block assem-
bly
,
Engine oil: Draining - Refilling
, page
10A-32
)
.
