10A-43
ENGINE AND CYLINDER BLOCK ASSEMBLY
Oil pressure sensor: Removal - Refitting
K4M
10A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Position the vehicle on a two-post lift (see Vehicle:
Towing and lifting) (02A, Lifting equipment).
a Remove:
-the engine undertray bolts,
-the engine undertray.
II - REMOVAL OPERATION
a Disconnect the oil pressure sensor connector (1) .
a Remove the oil pressure sensor.
REFITTING
I - REFITTING OPERATION
a Degrease the mating face of the oil pressure sensor
on the cylinder block using SURFACE CLEANER
(see Vehicle: Parts and consumables for the re-
pair) (04B, Consumables - Products).
a Refit the oil pressure sensor.
a Torque tighten the oil pressure sensor (35 N.m).
II - FINAL OPERATION
a Connect the oil pressure sensor connector.
a Refit the engine undertray.
Tightening torquesm
oil pressure sensor 35 N.m
116639
