57A-11
INTERIOR EQUIPMENT
Centre console: Removal - Refitting
57A
a Disconnect the cigarette lighter connector (5) .
a Remove the rear bolt of the centre console (6) .
a Remove:
- the centre console nut (7) ,
- the central bolts of the centre console (8) ,
- the side bolts of the centre console (9) ,
- the lower section of the centre console.
REFITTING
REFITTING OPERATION
a Proceed in the reverse order to removal.
WITH SMOKING ACCESSORIES
144833
144834
144832
Note:
Before clipping on the gear lever gaiter, position
the rear section of the gear lever gaiter on the
centre console.
