61A-7
HEATING
Heating: List and location of components
61A
3 Expansion valve (see 62A, Air conditioning, Expansion valve:
Removal - Refitting, page 62A-16)
4 Passenger compartment fan assembly control
unit
(see 61A, Heating, Passenger compartment
fan assembly control unit: Removal - Refit-
ting, page 61A-28)
5 Heater matrix (see 61A, Heating, Heater matrix: Removal -
Refitting, page 61A-21)
6 Air distribution cable (see 61A, Heating, Air distribution cable:
Removal - Refitting, page 61A-13)
7 Recirculation control cable (see 61A, Heating, Recirculation control
cable: Removal - Refitting, page 61A-11)
8 Air mixing cable (see 61A, Heating, Air mixing cable: Removal
- Refitting, page 61A-15)
9 Heating resistors (VALEO type) (see 61A, Heating, Heating resistors:
Removal - Refitting, page 61A-26)
10 Evaporator sensor (VALEO type) (see Evaporator sensor: Removal - Refitting)
11 Front side air distribution duct (see 61A, Heating, Front air distribution duct:
Removal - Refitting, page 61A-9)
12 Front central air distribution duct
13 C-pillar air distribution duct (see 61A, Heating, Rear air distribution duct:
Removal - Refitting, page 61A-10)
14 A-pillar air distribution duct (see Front footwell air distribution duct:
Removal - Refitting)
