61A-20
HEATING
Distribution unit: Removal - Refitting
61A
III - FINAL OPERATION
a Refit the floor carpet.
a Connect the heating resistor connector.
a Refit:
-the heating resistor relay mounting,
-the heating resistor relay mounting bolt.
a Clip on:
-the starter switch connector on its mounting.
-the wiring at (6) .
a Clip:
-the wiring on the distribution unit at (5) ,
-the wiring at (4) .
a Refit:
-the steering column (see Steering column: Re-
moval - Refitting) (36A, Steering assembly),
-the front air distribution ducts (see 61A, Heating,
Front air distribution duct: Removal - Refitting,
page 61A-9) ,
-the dashboard (see Dashboard: Removal - Refit-
ting) (57A, Interior equipment),
-the instrument panel (see Instrument panel: Re-
moval - Refitting) (83A, Instrument panel),
-the steering column switch assembly (see Steer-
ing column switch assembly: Removal - Refit-
ting) (84A, Control - Signals),
-the steering wheel (see Steering wheel: Removal
- Refitting) (36A, Steering assembly),
-the radio (see Radio: Removal - Refitting) (86A,
Radio),
-the storage compartment,
-the driver's front airbag (see Driver's frontal air-
bag: Removal - Refitting) (88C, Airbags and seat
belt pretensioners).
a Connect the heater hoses.
a Refit the clips on the heater hoses.
a Remove the hose clamps (Ms. 583).
a Replace the seals.
a Lubricate the seals using recommended air condi-
tioning oil to make fitting easier.
a Fit the pipe unions on the expansion valve.
a Refit the pipe union bolts on the expansion valve.
a Position the engine compartment bulkhead sound-
proofing.
a Consult the refrigerant and oil quantity values before
filling the circuit (see 62A, Air conditioning, Air
conditioning: Parts and consumables for the re-
pair, page 62A-9) .
a Fill the refrigerant circuit using the refrigerant
charging station (see Refrigerant circuit: Drain-
ing - Filling) .
a Check for leaks (see Refrigerant circuit: Check) .
a Check that the air conditioning is operating correctly
(see Air conditioning: Check) .
a Connect the battery (see Battery: Removal - Refit-
ting) (80A, Battery).
a Unlock the airbag computer (see Fault finding - Re-
placement of components) (88C, Airbags and pre-
tensioners).
a Fill the cooling circuit (see Cooling system: Drain-
ing - Refilling) (19A, Cooling).
a Bleed the cooling circuit (see Cooling system:
Draining - Refilling) (19A, Cooling).
a Check the cooling circuit (see Engine cooling sys-
tem: Check) (19A, Cooling).
Note:
Check that the floor carpet reaches under the
accelerator pedal end-stop.
DIESEL VEHICLE
AIR CONDITIONING
