62C-51
AFTER REPAIR Carry out a full check with the diagnostic tool.
V1
MR-453-X79-62C000$080.mif
CLIMATE CONTROL
Fault finding – Fault finding chart
62C
ALP 8
CONTINUED 1
Is the expansion valve pipe hot at the inlet and outlet?
Replace the expansion valve (see MR
451 Mechanical, 62A, Air
conditioning, Expansion valve:
Removal - Refitting).
Is the evaporator pipe hot at the inlet and outlet? Replace the evaporator.
Check fuse F01 of component 597.
Is the result of the check correct?
Replace the faulty fuse (see MR 451
Mechanical, 81C, Fuses, Fuses: List
and location of components).
A
YES
NO
YES
NO
NO
YES
1
To Next Page
