72A-4
SIDE OPENING ELEMENT TRIM
Rear side door trim: Removal - Refitting
72A
a Remove the rear side door armrest bolt (5) .
a Remove the rear side door interior handle bolts (6) .
a Remove the rear side door trim using a pair of un-
clipping pliers.
REFITTING
I - REFITTING PREPARATION OPERATION
a Check the condition of the clips and replace them if
necessary.
a Re-apply the bead of sealing mastic on the rear side
door trim using a BEAD OF PREFORMED SEAL-
ING MASTIC (see Vehicle: Parts and consum-
ables for the repair) (04B, Consumables -
Products).
II - REFITTING OPERATION
a Proceed in the reverse order to removal.
III - SPECIAL NOTES FOR REFITTING THE
MANUAL WINDOW WINDER
a Drill the trim at the centre of the mark (7) .
145614
EQUIPMENT LEVEL E2
144645
Note:
To facilitate fitting the rear side door trim,
dampen the box section where the seal is to be
applied.
109592
