75A-5
FRONT SEAT FRAMES AND MECHANISMS
Front seat assembly: Exploded view
FIXED SUBFRAME
75A
(see )
146034
Mark Description Information
1 Front seat backrest tilt control
4 Front seat headrest guide (see )
5 Front seat frame (see )
6 Front seatback angle control trim
7 Front seat belt buckle (see Front seat belt buckle:
Removal - Refitting)
8 Front seat runner
9 Front seat base frame
13 Bolt of front seat base exterior cas-
ing
14 Front seat base exterior casing
