75A-7
FRONT SEAT FRAMES AND MECHANISMS
Front seat assembly: Exploded view
FIXED SUBFRAME
75A
(see )
146035
Mark Description Information
1 Seat trim clip (Car.1521)
2 Front seatback cover (see )
3 Front seat base cover (see )
4 Front seat headrest (see )
5 Front seat back foam
6 Front seat base foam
FRONT SEAT WITH HEATING
Mark Description Information
7 Front seatback heated pad
8 Front seat base heated pad
