81B-3
INTERIOR LIGHTING
Interior light: Removal - Refitting
81B
REMOVAL
OPERATION FOR REMOVAL OF PART
CONCERNED
Front courtesy light
a Unclip the translucent cover (1) using a flat-blade
screwdriver or tool (Car. 1363), inserting it into the
notch (2) .
a Press on the clip (3) using the tool (Car. 1363) to re-
move the courtesy light.
a Disconnect the connector.
REFITTING
REFITTING OPERATION FOR PART CONCERNED
a Connect the connector.
a Refit the courtesy light.
a Clip the translucent cover in place.
Special tooling required
Car. 1363 Set of trim removal levers.
108749
108748
