81B-5
INTERIOR LIGHTING
Storage compartment light: Removal - Refitting
81B
REMOVAL
OPERATION FOR REMOVAL OF PART
CONCERNED
a
a Unclip the storage compartment light using the (Car.
1363).
a Disconnect the storage compartment light connec-
tor.
a Unclip the storage compartment light connector.
a Disconnect the storage compartment light switch
connector.
REFITTING
OPERATION FOR REFITTING PART CONCERNED
a
a Connect the storage compartment light switch con-
nector.
a Clip the storage compartment light connector.
a Connect the storage compartment light connector.
a Clip on the storage compartment light.
Special tooling required
Car. 1363 Set of trim removal levers.
Note:
It is not necessary to remove the dashboard.
107807
Note:
The glove compartment light switch can also be
removed.
Note:
When replacing a bulb, use an approved C5W
bulb.
