81C-1
FUSES
Fuses: List and location of components
81C
I - LIST OF COMPONENTS
II - LOCATION OF COMPONENTS
1 - PASSENGER COMPARTMENT FUSE BOX
This unit is located in the passenger compartment, on
the left-hand side of the dashboard.
Remove the cover to access the passenger compart-
ment fuse box.
Passenger compartment fuse box (1)
2 - ENGINE COMPARTMENT FUSE AND RELAY
BOX
Unclip the cover to access the passenger compartment
fuse and relay box.
No. Description
(1) Passenger compartment fuse box
(2),(3) Engine compartment fuse and relay
box
117677
107820
24729
