Rev. 1.50, 10/04, page 249 of 448

10.1.26 LDS (Load to System Register): System Control Instruction

Format Operation Instruction Code Cycle T Bit

LDS Rm,MACH Rm → MACH 0100mmmm00001010 1 —

LDS Rm,MACL Rm → MACL 0100mmmm00011010 1 —

LDS Rm,PR Rm→ PR 0100mmmm00101010 1 —

LDS.L @Rm+,MACH (Rm) → MACH, Rm + 4 → Rm 0100mmmm00000110 1 —

LDS.L @Rm+,MACL (Rm) → MACL, Rm + 4 → Rm 0100mmmm00010110 1 —

LDS.L @Rm+,PR (Rm) → PR, Rm + 4 → Rm 0100mmmm00100110 1 —

Description: Stores the source operand into the system registers MACH, MACL, or PR.

Notes: None

Operation:

LDSMACH(long m) /* LDS Rm,MACH */

{

MACH = R[m];

PC += 2;

}

LDSMACL(long m) /* LDS Rm,MACL */

{

MACL = R[m];

PC += 2;

}

LDSPR(long m) /* LDS Rm,PR */

{

PR = R[m];

PC += 2;

}
