Rev. 1.50, 10/04, page 35 of 448

Table 3.6 Logic Operation Instructions

Instruction Operation Instruction Code Privileged T Bit New

AND Rm,Rn Rn & Rm → Rn

0010nnnnmmmm1001

— — —

AND #imm,R0 R0 & imm → R0

11001001iiiiiiii

— — —

AND.B #imm, @(R0,GBR) (R0 + GBR) & imm

→ (R0 + GBR)

11001101iiiiiiii

— — —

NOT Rm,Rn ~Rm → Rn

0110nnnnmmmm0111

— — —

OR Rm,Rn Rn | Rm → Rn

0010nnnnmmmm1011

— — —

OR #imm,R0 R0 | imm → R0

11001011iiiiiiii

— — —

OR.B #imm, @(R0,GBR) (R0 + GBR) | imm

→ (R0 + GBR)

11001111iiiiiiii

— — —

TAS.B @Rn When (Rn) = 0, 1 → T

Otherwise, 0 → T

In both cases,

1 → MSB of (Rn)

0100nnnn00011011

— Test

result

—

TST Rm,Rn Rn & Rm;

when result = 0, 1 → T

Otherwise, 0 → T

0010nnnnmmmm1000

— Test

result

—

TST #imm,R0 R0 & imm;

when result = 0, 1 → T

Otherwise, 0 → T

11001000iiiiiiii

— Test

result

—

TST.B #imm, @(R0,GBR)

(R0 + GBR) & imm;

when result = 0, 1 → T

Otherwise, 0 → T

11001100iiiiiiii

—

Test

result

—

XOR Rm,Rn

Rn ∧ Rm → Rn 0010nnnnmmmm1010

—

XOR #imm,R0

R0 ∧ imm → R0 11001010iiiiiiii

—

XOR.B #imm, @(R0,GBR)

(R0 + GBR) ∧ imm →

(R0 + GBR)

11001110iiiiiiii

—
