Renesas SuperH SH-4A User Manual

Rev. 1.50, 10/04, page 31 of 448
Table 3.4 Fixed-Point Transfer Instructions
Instruction Operation Instruction Code Privileged T Bit New
MOV
#imm,Rn imm → sign extension → Rn
1110nnnniiiiiiii
— — —
MOV.W
@(disp*,PC), Rn (disp × 2 + PC + 4) → sign
extension → Rn
1001nnnndddddddd
— — —
MOV.L
@(disp*,PC), Rn (disp × 4 + PC & H'FFFF FFFC
+ 4) → Rn
1101nnnndddddddd
— — —
MOV
Rm,Rn Rm → Rn
0110nnnnmmmm0011
— — —
MOV.B
Rm,@Rn Rm → (Rn)
0010nnnnmmmm0000
— — —
MOV.W
Rm,@Rn Rm → (Rn)
0010nnnnmmmm0001
— — —
MOV.L
Rm,@Rn Rm → (Rn)
0010nnnnmmmm0010
— — —
MOV.B
@Rm,Rn (Rm) → sign extension → Rn
0110nnnnmmmm0000
— — —
MOV.W
@Rm,Rn (Rm) → sign extension → Rn
0110nnnnmmmm0001
— — —
MOV.L
@Rm,Rn (Rm) → Rn
0110nnnnmmmm0010
— — —
MOV.B
Rm,@-Rn Rn-1 → Rn, Rm → (Rn)
0010nnnnmmmm0100
— — —
MOV.W
Rm,@-Rn Rn-2 → Rn, Rm → (Rn)
0010nnnnmmmm0101
— — —
MOV.L
Rm,@-Rn Rn-4 → Rn, Rm → (Rn)
0010nnnnmmmm0110
— — —
MOV.B
@Rm+,Rn (Rm)→ sign extension → Rn,
Rm + 1 → Rm
0110nnnnmmmm0100
— — —
MOV.W @Rm+,Rn (Rm) → sign extension → Rn,
Rm + 2 → Rm
0110nnnnmmmm0101
— — —
MOV.L @Rm+,Rn (Rm) → Rn, Rm + 4 → Rm
0110nnnnmmmm0110
— — —
MOV.B R0,@(disp*,Rn) R0 → (disp + Rn)
10000000nnnndddd
— — —
MOV.W R0,@(disp*,Rn) R0 → (disp × 2 + Rn)
10000001nnnndddd
— — —
MOV.L Rm,@(disp*,Rn) Rm → (disp × 4 + Rn)
0001nnnnmmmmdddd
— — —
MOV.B @(disp*,Rm),R0 (disp + Rm) → sign extension
→ R0
10000100mmmmdddd
— — —
MOV.W @(disp*,Rm),R0 (disp × 2 + Rm) → sign
extension → R0
10000101mmmmdddd
— — —
MOV.L @(disp*,Rm),Rn (disp × 4 + Rm) → Rn
0101nnnnmmmmdddd
— — —
MOV.B Rm,@(R0,Rn) Rm → (R0 + Rn)
0000nnnnmmmm0100
— — —
MOV.W Rm,@(R0,Rn) Rm → (R0 + Rn)
0000nnnnmmmm0101
— — —
MOV.L Rm,@(R0,Rn) Rm → (R0 + Rn)
0000nnnnmmmm0110
— — —
MOV.B @(R0,Rm),Rn (R0 + Rm) →
sign extension → Rn
0000nnnnmmmm1100
— — —
MOV.W @(R0,Rm),Rn (R0 + Rm) →
sign extension → Rn
0000nnnnmmmm1101
— — —
MOV.L @(R0,Rm),Rn (R0 + Rm) → Rn
0000nnnnmmmm1110
— — —
