Rev. 1.50, 10/04, page 54 of 448
4.2 Parallel-Executability
Instructions are categorized into six groups according to the internal function blocks used, as
shown in table 4.2. Table 4.3 shows the parallel-executability of pairs of instructions in terms of
groups. For example, ADD in the EX group and BRA in the BR group can be executed in parallel.
Table 4.2 Instruction Groups
Instruction
Group
Instruction
EX ADD
ADDC
ADDV
AND #imm,R0
AND Rm,Rn
CLRMAC
CLRS
CLRT
CMP
DIV0S
DIV0U
DIV1
DMUS.L
DMULU.L
DT
EXTS
EXTU
MOVT
MUL.L
MULS.W
MULU.W
NEG
NEGC
NOT
OR #imm,R0
OR Rm,Rn
ROTCL
ROTCR
ROTL
ROTR
SETS
SETT
SHAD
SHAL
SHAR
SHLD
SHLL
SHLL2
SHLL8
SHLL16
SHLR
SHLR2
SHLR8
SHLR16
SUB
SUBC
SUBV
SWAP
TST #imm,R0
TST Rm,Rn
XOR #imm,R0
XOR Rm,Rn
XTRCT
MT MOV #imm,Rn MOV Rm,Rn NOP
BR BF
BF/S
BRA
BRAF
BSR
BSRF
BT
BT/S
JMP
JSR
RTS
LS FABS
FNEG
FLDI0
FLDI1
FLDS
FMOV @adr,FR
FMOV FR,@adr
FMOV FR,FR
FMOV.S @adr,FR
FMOV.S FR,@adr
FSTS
LDC Rm,CR1
LDC.L @Rm+,CR1
LDS Rm,SR1
LDS Rm,SR2
LDS.L @adr,SR2
LDS.L @Rm+,SR1
LDS.L @Rm+,SR2
MOV.[BWL] @adr,R
MOV.[BWL] R,@adr
MOVA
MOVCA.L
MOVUA
OCBI
OCBP
OCBWB
PREF
STC CR2,Rn
STC.L CR2,@-Rn
STS SR2,Rn
STS.L SR2,@-Rn
STS SR1,Rn
STS.L SR1,@-Rn
FE FADD
FSUB
FCMP (S/D)
FCNVDS
FCNVSD
FDIV
FIPR
FLOAT
FMAC
FMUL
FRCHG
FSCHG
FSQRT
FTRC
FTRV
FSCA
FSRRA
FPCHG
