Renesas SuperH SH-4A User Manual

Rev. 1.50, 10/04, page 429 of 448
Module Name Abbreviation R/W P4 Address*
Area 7
Address*
Access
Size
L memory L memory transfer source
address register 0
LSA0 R/W H'FF00 0050 H'1F00 0050 32
L memory transfer source
address register 1
LSA1 R/W H'FF00 0054 H'1F00 0054 32
L memory transfer
destination address
register 0
LDA0 R/W H'FF00 0058 H'1F00 0058 32
L memory transfer
destination address
register 1
LDA1 R/W H'FF00 005C H'FF00 005C 32
Note: * The P4 address is the address used when using P4 area in the virtual address space.
The area 7 address is the address used when accessing from area 7 in the physical
address space using the TLB.
