RFL 9300 RFL Electronics Inc.

October 20, 2004 5-12 (973) 334-3100

Table 5-1. Pin assignment for DC-37 connector on RFL 93 DD I/O Direct Digital I/O Module

Pin No.

Signal Name Description

1 SHLDGND Shell ground (chassis ground)

19 GND Signal ground

25 GND Signal ground

7 +5V +5-volt signal

4 SD A TX DATA output + (RS-422)

22 SD B TX DATA output -

5 ST A SEND TIMING input + (RS-422)

23 ST B SEND TIMING input -

6 RD A RX DATA input + (RS-422)

24 RD B RX DATA input -

8 RT A RECEIVE TIMING input + (RS-422)

26 RT B RECEIVE TIMING input -

33 /ALARM EXTERNAL ALARM input (logic - level). Pull-up to +5V to drive alarm; low to signal ground
