Table 18-3. Replaceable parts, RFL 93 FT/FR I/O Singlewidth fiber optic I/O modules
RFL 93 FT/FR I/O-13M (Singlemode) (Assembly No. 105855)
RFL 93 FT/FR I/O-13S (Multimode) (Assembly No. 105860)
Circuit symbol
(Figs 18-10 & 18-11)
Description Part number
CAPACITORS
C1, 2, 13, 14, 19, 20, 21, 25, 26, Capacitor, ceramic, 0.1 μF, 20%, 50V 1007 1366
27, 34, 35, 49, 50, 51
C7, 15, 28, 29, 30, 36, Capacitor, ceramic, dipped, 0.01 μF, 5%, 100V 1007 1645
37, 43, 44
C9 Capacitor, electrolytic, 100 μF, 20%, 25V 1007 1630
C10, 11, 18, 22, 33, Capacitor, tantalum, 1 μF, 10%, 35V 1007 1768
32, 46, 47, 48
C12 Capacitor, tantalum, 22 μF, 20%, 16V 1007 1569
C16 Capacitor, ceramic, 5 pF +1 -0.5 pF, 200V 0125 25R04
C23 Capacitor, ceramic, dipped, 10 pF, 10%, 200V 1007 1462
C31, 38, 39, 41, 45 Capacitor, ceramic, dipped, 0.1 μF, 10%, 50V 1007 1769
C40, 42 Capacitor, ceramic, dipped, 100 pF, 10%, 100V 1007 1671
RESISTORS
R1, 10 Resistor, metal film, precision, 499Ω, 1%, 1/4W 0410 1259
R15, 17, 41, 43 Resistor, metal film, precision, 1K, 1%, 1/4W 0410 1288
R9
R11
Resistor, metal film, precision, 23.7Ω, 1%, 1/2W
Resistor, metal film, precision, 11.87K, 1%, 1/2W
1510 2132
0410 1314
R12, 18, 16 Resistor, metal film, precision, 100K, 1%, 1/4W 0410 1480
R13 Resistor, metal film, precision, 3.09K, 1%, 1/4W 0410 1335
R14 Resistor, metal film, precision, 20K, 1%, 1/4W 0410 1413
R19 Resistor, metal film, precision, 3.01K, 1%, 1/4W 0410 1334
R20 Resistor, metal film, precision, 16.9K, 1%, 1/4W 0410 1406
R22, 25 Resistor, metal film, precision, 24.9K, 1%, 1/4W 0410 1422
R23, 24, 35, 38 Resistor, metal film, precision, 182Ω, 1%, 1/4W 0410 1217
R26 Resistor, metal film, precision, 133K, 1%, 1/4W 0410 1492
R27, 29 Resistor, metal film, precision, 110K, 1%, 1/4W
0410 1484
