RFL 9300 RFL Electronics Inc.
January 30, 2002 6-21 (973) 334-3100
Table 6-6. READ mode parameters for RFL 9300 Three-Terminal Charge Comparison Systems
No. Display Definition
... Moving dots RFL 9300 is in STANDBY mode. Display controller parameter; not user-selectable.
0 EXIT Exit to STANDBY mode. Display function; can be set to either ENABLE or DISABLE. (1)
1 PngPng 1 Value of ping-pong (round-trip delay) for remote 1.
2 PngPng 2 Value of ping-pong (round-trip delay) for remote 2.
5 LOC IA Local Phase A current.
6 LOC IB Local Phase B current.
7 LOC IC Local Phase C current.
8 LOC 3I0 Local 3I0 current.
9 REM1 IA Remote 1 Phase A current.
10 REM1 IB Remote 1 Phase B current.
11 REM1 IC Remote 1 Phase C current.
12 REM1 3I0 Remote 1 3I0 current.
13 REM2 IA Remote 2 Phase A current.
14 REM2 IB Remote 2 Phase B current.
15 REM2 IC Remote 2 Phase C current.
16 REM2 3I0 Remote 2 3I0 current.
17 RCV ADD1 Remote 1 Rx address. (2)
18 RCV ADD2 Remote 2 Rx address. (3)
19 ALARMS Present alarm status (four alarms).
20 PH BIAS Phase bias. Programmable; see table 6-10 for more information.
21 GND BIAS Ground bias. Programmable; see table 6-10 for more information.
22 BIAS CTL Bias control. Programmable; see table 6-10 for more information.
23 GND DLY Enable/disable ground delay. Programmable; see table 6-10 for more information.
24 DLAY SEC Bias control and ground delay time (in seconds). Programmable; see table 6-10 for more information.
25 FD PHASE Local phase fault detector current. Programmable; see table 6-10 for more information.
26 FD GND Local ground fault detector current. Programmable; see table 6-10 for more information.
27 BACKUP System backup functions. Programmable; see table 6-10 for more information.
28 PH OC BU Phase overcurrent backup. Programmable; see table 6-10 for more information.
29 G OC BU Ground overcurrent backup. Programmable; see table 6-10 for more information.
30 P TOC Phase inverse time-overcurrent backup. Programmable; see table 6-10 for more information.
31 PPKUP Phase inverse time-overcurrent pickup value. Programmable; see table 6-10 for more information.
32 PCURV Phase inverse time-overcurrent curve select value. Programmable; see table 6-10 for more information.
33 PDIAL Phase inverse time-overcurrent dial setting value. Programmable; see table 6-10 for more information.
34 G TOC Ground inverse time-overcurrent backup. Programmable; see table 6-10 for more information.
35 GPKUP Ground inverse time-overcurrent pickup value. Programmable; see table 6-10 for more information.
36 GCURV Ground inverse time-overcurrent curve select value. Programmable; see table 6-10 for more information.
37 GDIAL Ground inverse time-overcurrent dial setting value. Programmable; see table 6-10 for more information.
38 OVHD/UGD Overhead or underground cable. Programmable; see table 6-10 for more information.
39 OPEN CON Open conductor action. Programmable; see table 6-10 for more information. (7)
40 STUB BUS Stub bus active/inactive.
>> Table continues on next page <<
>> Refer to page 6-24 for notes <<
