Table 24-2. Replaceable parts, RFL 9300 single pole chassis
Assembly No. 106710
Circuit Symbol
(Figs. 24-4 & 24-5)
Description Part Number
CAPACITORS
C1-3 Capacitor, electrolytic, 22μF, 100V 1007 1429
C4-13, 15-18, 21, 23-29, Capacitor, ceramic dip, 0.1μF, 10%, 50V 0120 38
31-34, 36
C14, 22, 30, 37, 38, 39 Capacitor, tantalum, 100μF, 20%, 20V 1007 883
C35 Capacitor, ceramic dip, 0.01μF, 10%, 100V 1007 1390
RESISTORS
R1 Resistor, metal film, axial, 49.9K, 1%, 1/4W 0410 1451
R2 Resistor, metal film, axial, 3.01K, 1%, 1/4W 0410 1334
R3, 6 Resistor, metal film, axial, 5.9K, 1%, 1/4W 0410 1362
R4 Resistor, metal film, axial, 6.81K, 1%, 1/4W 0410 1368
R5 Resistor, metal film, axial, 3.16K, 1%, 1/4W 0410 1336
R7, 13, 24, 31, 40, 47, 67 Resistor, metal film, axial, 10K, 1%, 1/4W 0410 1384
R9, 10, 14, 15, 25, 26, 32, Resistor, metal film, axial, 1K, 1%, 1/4W 0410 1288
33, 41, 42, 48, 49, 60-
65
R11, 12, 27, 28, 43, 44,
66,
Resistor, metal film, axial, 200Ω, 1%, 1/2W 0410 2221
71, 72
R16-21, 29, 30, 36-39, 45, Resistor, metal film, axial, 69.8Ω, 1%, 1/4W 0410 1177
46, 52-55
R22, 23, 34, 35, 50, 51,
56,
Resistor, metal film, axial, 499Ω, 1%, 1/4W 0410 1259
57, 58, 68, 69, 70
R59 Resistor, metal film, axial, 100Ω, 1%, 1/4W 0410 1192
RZ1 Resistor, network, 100K, 9R/PKG 32623
SEMICONDUCTORS
CR1-5, 8-10, 12-14 Diode, silicon , rectifier, 1 Amp, 1N4003 30769
CR6, 7, 11 Diode, Schottky, 1 Amp, 20 Volt, 1N5817 30150
Q1 Transistor, silicon, PNP, 2N3906 21565
Q2 Transistor, NPN, 40 Volts, 2N4401 42574
U1 Integrated circuit, MOS, field programmable gate array 0615 450
U2, 3, 4 Transistor, array, ULN2803A 0720 7
MISCELLANEOUS COMPONENTS
DS1-2 Optoelectric device, LED, green 32567
DS3-12 Optoelectric device, LED, red 99294
J1 Connector, wafer assembly, 8 circuit 45142 8
J2, 3, 4 Connector, male, 15 pin, DIN41612 102868
JP1 Connector, JK male, 26 pin, vertical 95617
K1, 2 Relay, SPDT, 12 Volt, PCB, sealed 101236
K3-8, 11-16, 19-24 Relay, SPST, 12Vdc, 37.5ma, special 102860
K9, 10, 17, 18, 25, 26 Relay, reed, SPST, 100 Volt, 250ma 102859
TP1-29 Test point, terminal, orange 98441 3
Y1
Crystal, hybrid, clock oscillator, 3.584 mHz 103347
RFL 9300 RFL Electronics Inc.
August 25, 2000 24 - 12 (973) 334-3100
