Table 20-1. Replaceable parts, RFL 93B Relay I/O, Power/RS-232 board
(Assembly No. 106388-1)
Circuit Symbol
(Figs. 20-4 & 20-7)
Description Part Number
CAPACITORS
C101,105,108,109,112 Capacitor,ceramic,0.1uf,10%,100V 0130 11041
C102,103 Capacitor,tantalum,3.3uf,20%,35V 1007 1260
C106,107 Capacitor,ceramic,0.01uf,10%,100V 0130 11031
C110,111 Capacitor,ceramic disc,0.005uf,20%,3KV 1007 1264
RESISTORS
R101,102,108 Resistor,metal film,axial,3.01K,1%,1/4W 0410 1334
R103,104
Resistor,metal film,axial,715
Ω,1%,1/4W
0410 1274
R105,106 Resistor,metal film,axial,1K,1%,1/4W 0410 1288
R107
Resistor,metal film,axial,100
Ω,1%,1/2W
0410 2192
R109
Resistor,metal film,axial, 150
Ω,1%,1/4W
0410 1209
RZ101
Resistor,network,150
Ω,5R/PKG,SIP
100571
SEMICONDUCTORS
CR101,102 Diode,Zener,silicon,9.1V,1N960B 41014
CR103,105,106,111 Suppressor,transient,voltage,P6KE30CA 100567
CR104,107 Suppressor,transient,voltage,P6KE16CA 100572
CR108,109 Diode,rectifier,silicon,3A,1N5406 101716
CR110 Suppressor,transient,voltage,1.5KE200CA 30266
MISCELLANEOUS COMPONENTS
F1,2 Fuse,10A,3AG,250V,normal-blow 44395 010
J3 Connector, JK male,9P,RT angle 101106
L101,102
Inductor,10
μH,5%,1.5A max
30285
P101 Connector,plug,female,64 cont,DIN 99134
TP101,102,103 Test point,terminal,orange 98441
