RFL 9300 RFL Electronics Inc.
January 30, 2002 6-29 (973) 334-3100
Table 6-10. Programmable parameters, RFL 9300 Three-Terminal Charge Comparison System
No. Display Definition Range Step Default
20 PH BIAS Phase bias 1.0 to 8.0 A 0.5 A 8.0 A
21 GND BIAS Ground bias 1.0 to 2.25 A 0.25 A 2.25 A
22 BIAS CTL Bias control ENABLE/DISABLE . . . ENABLE
23 GND DLY Ground delay ENABLE/DISABLE . . . ENABLE
24 DLAY SEC Bias control and ground delay time Bias: 50 to 1000 ms
Ground: 50 ms to 30 s
50 ms
Variable
(1)
1000 ms
30 s
25 FD PHASE Local phase fault detector current 6 or 8 A . . . 8 A
26 FD GND Local ground fault detector current 0.5 or 1.0 A . . . 1.0 A
27 BACKUP System backup functions
ENABLE/DISABLE
(8)
. . . DISABLE
28 PH OC BU Phase overcurrent backup 6 to 31.875 A 0.125 A 31.875 A
29 G OC BU Ground overcurrent backup 1 to 31 A 0.125 A 31 A
30
PH TOC
Phase inverse time-overcurrent enable/disable
ENABLE/DISABLE . . . DISABLE
31
P PICKUP
Phase inverse time-overcurrent pickup value
0.5 to 31.875 A 0.125 A 31.875 A
32
PH CURVE
Phase inverse time-overcurrent curve select
See note 6 . . . USA1
33
PH DIAL
Phase inverse time-overcurrent dial setting
See note 6 . . . SET 15.0
34
GND TOC
Ground inverse time-overcurrent enable/disable
ENABLE/DISABLE . . . DISABLE
35
G PICKUP
Ground inverse time-overcurrent pickup value
0.5 to 31.0 A 0.125 A 31.0 A
36
G CURVE
Ground inverse time-overcurrent curve select
See note 7 . . . USA1
37
GND DIAL
Ground inverse time-overcurrent dial setting
See note 7 . . . SET 15.0
38 OVHD/UGD Overhead or underground cable OVHD or UGD . . . UGD
39 OPEN CON Open conductor action ALARM or TRIP . . .
ALARM
(9)
41 CM ALM D Communications alarm delay ENABLE/DISABLE . . . ENABLE
43 DEFAULT Resets Parameter #'s 20 - 52 to default values ENABLE/DISABLE . . .
DISABLE
(2)
44 BEEPER Enable/disable audible beeper ENABLE/DISABLE . . .
ENABLE
(3)
45 DISPLAY Adjust display intensity 4 levels . . .
Brightest
(4
)
46 XMIT ADD1 Select transmit address 1 16 to 4095 1 0000
47 XMIT ADD2 Select transmit address 2 16 to 4095 1 0000
50 G B4 TRP Guard before trip ENABLE/DISABLE . . . ENABLE
51 RS232 BD Selects RS-232 baud rate 1200, 2400, 9600 . . . 1200
52 RS232 PR Selects RS-232 handshaking protocol XON/XOFF or RTS/CTS . . . XON/XOFF
141 SEL POLE Single-Pole trip method
ENABLE/DISABLE
(10
)
. . . DISABLE
145 TRIP RLS Selects mode of trip release
3 choices
(11
)
. . . TRIP+100
Notes for Tables 6-9 and 6-10:
1. Bias control and ground delay settings will track each other from 50 ms to 750 ms. Above 750 ms, the ground delay varies in non-
proportional steps:
Bias Ground
800 ms 2 s
850 ms 5 s
900 ms 10 s
950 ms 15 s
1000 ms 30 s
2. When this parameter is enabled and the [ENT] key is pressed, the Display Controller requests that the PROGRAM mode security code
(.248) be entered. Once it is, all parameter values will be reset to the default values listed above. These are the values the parameters
are set to before the RFL 9300 leaves the factory.
>> Notes continue on next page <<
