27.13 DNP POINT LIST (Version A1,M13,8/3/01)
Table 27-4. POINT LIST FOR: 16 bit Analog without Flag (Object 30 Var 4)
Index Description Units Format Write? Default
0000 130 Terminals (2 or 3) - F3 No 0
0001 132 CT Full Scale (1: 1 Amp/5: 5 Amp) - F4 No 0
0002 133 Frequency (50 or 60 Hz) - F5 No 0
0003
140 Single Pole (Inactive:I=73 ASCII Active: A=65 ASCIII )
F20
0004 SW ID CC1 - F1 No 0
0005 SW ID CC2 - F1 No 0
0006 SW ID SV - F1 No 0
0007 SW ID PCA - F1 No 0
0008 SW ID PCB - F1 No 0
0009 SW ID PCC - F1 No 0
0010 SW ID PCG - F1 No 0
0011 SW ID DC - F1 No 0
0012 Phase Bias (Amp) value/1000 A F2 No 0
0013 Ground Bias (Amp) A F1 No 0
0014 Bias Control (Disable D=68 Ascii Enable E=69 Ascii) - F20 No 0
0015 Ground Bias (Disable D=68 Ascii Enable E=69 Ascii) - F20 No 0
0016 Bias (seg.) value/10 Sec F7 No 0
0017 Ground Dly (seg.) Sec F1 No 0
0018 F.D. Phase (Amp.) value/10 A F7 No 0
0019 F.D. Ground (Amp.) A F1 No 0
0020 Backup (Disable D=68 Ascii Enable E=69 Ascii) - F20 No 0
0021 Phase O/C Backup (Amp.) value/10000 A F8 No 0
0022 Ground O/C Backup (Amp.) value/10000 A F8 No 0
0023 Phase TOC (Disable D=68 Ascii Enable E=69 Ascii) - F20 No 0
0024 PH TOC Pickup (Amp.) value/1000 - F2 No 0
0025 PH TOC Curve (IEC: I=73 Ascii USA: U=85 Ascii) - F20 No 0
0026 PH TOC Curve (1,2,3 or 4) F1 No
0027 PH TOC Dial value/100 - F6 No 0
0028 GroundTOC (Disable D=68 Ascii Enable E=69 Ascii) - F20 No 0
0029 Gd TOC Pickup value/1000 - F2 No 0
0030 Gd TOC Curve (IEC: I=73 Ascii USA: U=85 Ascii) - F20 No 0
0031 Gd TOC Curve (1,2,3,or 4) F1
0032 Gd Toc Dial value/10 - F7 No 0
0033 Overhd/ Undergd (U= 85 Ascii O=79 Ascii) - F20 No 0
0034 Open Conductor (T=84 Ascii A=65 Ascii) - F20 No 0
0035 Stub Bus (Inacctive I=73 Ascii Active A:65 Ascii) - F20 No 0
0036 Comms Alm Dly (DisableD=68 Ascii EnableE=69 Ascii) - F20 No 0
0037 DC Offset Filter (DisableD=68 Ascii EnableE=69 Ascii) - F20 No 0
0038 Beeper (DisableD=68 Ascii EnableE=69 Ascii) D F20 No All 1s
0039 Transmit Addr 1 (value/1000) D F2 No All 1s
