Table 27-4. POINT LIST FOR: 16 bit Analog Without Flag (Object 30 Var 4) - continued
Index Description Units Format Write? Default
0040 Comms Mode (A=65 Ascii M=77 Ascii) T F20 No All 1s
0041 Active Channel 1or 2 - F1 No All 1s
0042 Guard/Trip (D=68 Ascii I=73 Ascii) - F20 No 0
0043 Resest Disp. Alrm (N=78 Ascii Y=89 Ascii) - F20 No 0
0044 Alarm Trigger (E=69 Ascii D=68 Ascii) - F20 No 0
0045 Single Pole (I=73 Ascii A=65 Ascii) - F20 No 0
0046 Trip Release (+100=1 +0=0 +CS=67 67=C Ascii) - F17 No 0
0047 System Label (only one char) - F20 No 0
0048 Alarm Status (0 No Alarm) - F16 No 0
0049 Osc. Phase A Data 1 - - No 0
0050 Osc. Phase B Data 1 - - No 0
0051 Osc. Phase C Data 1 - - No 0
0052 Osc. Phase 3IO Data 1 - - No 0
------ -------- - - No 0
------ -------- - - No 0
0845 Osc. Phase A Data 200 - - No 0
0846 Osc. Phase B Data 200 - - No 0
0847 Osc. Phase C Data 200 - - No 0
0848 Osc. Phase 3IO Data 200 - - No 0
0849 Osc. Algorith Code 1 - - No 0
0850 Osc. Algorith Code 2 - - No 0
0851 Osc. Algorith Code 3 - - No 0
------ --------
------ --------
1047 Osc. Algorith Code 199 - - No 0
1048 Osc. Algorith Code 200 - - No 0
Table 27-5. POINT LIST FOR: Binary Input Change with Tim (Object 02 Var 2)
Index Description Units Format Write? Default
0000
Last Alarm
- - No -
0001 Historic Alarm 1 - - No -
0002 Historic Alarm 2 - - No -
0003 Historic Alarm 3 - - No -
0004 Historic Alarm 4 - - No -
0005 Historic Alarm 5 - - No -
0006 Historic Alarm 6 - - No -
0007 Historic Alarm 7 - - No -
0008 Historic Alarm 8 - - No
0009 Historic Alarm 9 - - No
0010 Oscillography Data Status (Osc. Date Time) - - No
