RFL Electronics RFL 9300 - Figure 6-29. Typical Parameter Settings List for a Three-Terminal System

6.5.12.1 CHANGING THE PASSWORD
You can use the "C" command to change the second password that can be used to enter the programming
mode.
Format: 9300-P>C [ENTER]
When you enter the "C" command, the RFL 9300 sends the following prompt to your terminal:
enter super-user:
Enter the super-user password ("CDLNRW"), and then press [ENTER]. The following prompt will appear:
Current password is (current password)
enter new password:
Enter the new password, and then press [ENTER]. The following prompt will appear:
repeat new password:
Enter the new password again, and then press [ENTER]. The following prompt will appear:
password modified
The new password is now stored in the RFL 9300's non-volatile RAM memory.
6.5.12.2 DISPLAYING PARAMETER SETTINGS
To view a list of all current parameter settings, use the "D" command.
Format: 9300-P>D [ENTER]
When you enter the "D" command, the RFL 9300 sends a list of all current parameter settings to your terminal.
A typical parameter settings list for a three-terminal system is shown in Figure 6-29.
9300-P>D
#
020
022
024
026
028
030
032
034
036
038
041
046
050
121
122
141
999
9300-P>
PARAMETER
Phase Bias
Bias Control
Bias/Ground Dly
F.D. Ground
Phase O/C Bkup
Phase TOC
(2)
PhTOC Curve
Ground TOC
(3)
Gd TOC Curve
Overhd/Undergd
Comms Alm Dly
Transmit Addr 1
Guard/Trip
Current Time
Reset Disp. Alrm
Slctv Pole RL
System Label
SETTING
1.500 Amps
Disable
.05/.05 sec
1.0 Amp
31.875 Amps
Disable
N/A
Disable
N/A
Overhead
Disable
4079
Disable
09:29:27
No
Disable
Gen1
#
021
023
025
027
029
031
033
035
037
040
044
047
120
140
145
PARAMETER
Ground Bias
Ground Delay
F.D. Phase
Backup
(1)
Ground O/C Bkup
Ph TOC Pickup
Ph TOC Dial
Gd TOC Pickup
Gd TOC Dial
Stub Bus
(1)
Beeper
Transmit Addr 2
Current Date
Single Pole
Trip Release
SETTING
1.500 Amps
Enable
8.0 Amps
Enable
31.000 Amps
N/A
N/A
N/A
N/A
Inactive
Disable
4075
08/16/00
Active
CS+TRIP
Figure 6-29. Typical parameter settings list for a three-terminal system
NOTE
If parameter No. 030 is disabled, then parameter numbers 031, 032 and 033 will display N/A (not applicable).
If parameter No. 034 is disabled, then parameter numbers 035, 036 and 037 will display N/A (not applicable).
RFL 9300 RFL Electronics Inc.
January 30, 2002 6-58 (973) 334-3100
