RFL Electronics RFL 9300 - Table 16-1. Replaceable Parts, RFL 93 DD I;O Direct Digital Interface I;O Module

RFL 9300 RFL Electronics Inc.
May 1, 1998 16 - 4 (973) 334-3100
Table 16-1. Replaceable parts, RFL 93 DD I/O Direct Digital Interface I/O Module
(Assembly No. 103830-1)
Circuit Symbol
(Figs. 16-3 & 16-4)
Description Part Number
C1-4,6
C5
C7
C8-10
CR1-4
CR5-12
J2,3
L1,2
R1
R3
R5,6
R7
R8-13
R20-23
RZ1
U1
U2
U3
U4
U5
Capacitor,X7R ceramic,0.1uF,10%,50V,AVX SA305C104KAA or equiv.
Capacitor,tantalum,1uF,20%,35V,Kemet T322B105M035AS or equiv.
Capacitor,X7R ceramic,0.01uF,10%,50V,AVX SA105C103KAA or equiv.
Capacitor, ceramic 220pF, 10%,100V
Diode, Shottky, 1A, 20V, 1N5817
Suppressor, voltage, P6KE9.1CA
Shorting bar,single,Molex 90059-0009 or equiv.
Inductor,powerline,10mH,Renco RL-1283-10 or equiv.
Resistor,metal film,100Ω,1%,1/2W, Type RN1/2
Resistor,metal film,1KΩ,1%,1/4W, Type RN1/4
Resistor,metal film,4.99KΩ,1%,1/4W, Type RN1/4
Resistor,metal film,121Ω,1%,1/4W, Type RN1/4
Resistor, metal film, 499Ω, 1%,1/4W, Type RN 1/4
Resistor, metal film, 15Ω, 1%, 1/4W
Resistor network,nine 10KΩ 2% resistors,1.25W total,10-pin SIP,Bourns 4310R-101-103 or equiv.
MOS quad differential line driver,16-pin DIP,National Semiconductor DS34C87N or equiv.
MOS quad differential line receiver,16-pin DIP,National Semiconductor DS34C86N or equiv.
MOS quad 2-input NAND gate,14-pin DIP,National Semiconductor MM74HC00N or equiv.
MOS quad 2-input multiplexer,16-pin DIP,National Semiconductor MM74HC157N or equiv.
MOS quad 2-input Exclusive-OR gate,14-pin DIP,RCA CD74HCT86E or equiv.
0130 51041
1007 496
0130 51031
0125 12211
30150
103340
98306
30063
0410 2192
0410 1288
0410 1355
0410 1200
0410 1259
1510 1023
32622
0615 395
0615 394
0615 159
0615 171
0615 390
