6.5.8 THE UPDATE MODE
The update mode places a display on your terminal that is constantly updated to show up-to-date information
about RFL 9300 operation. This mode is entered by using the "U" command.
Format: 9300>U [ENTER]
When the "U" command is entered, the screen on your terminal will be cleared, and replaced by the UPDATE
screen shown in Figure 6-20 for a two-terminal system and Figure 6-21 for a three-terminal system. This is a
display of all the measured parameter values. The displayed values are updated about once a second when
operating at 2400 baud. This screen can be used to monitor RFL 9300 operation. To exit the update mode,
press the [X] key, followed by the [ENTER] key. The screen on your terminal will be cleared, and the "9300>"
prompt will re-appear.
Value Update - Type 'X<CR>' to Stop
001 Ping Pong #1 004.0 ms
003 CDC #1 004.0 ms
005 Local I A 00.00 amps
006 Local I B 00.00 amps
007 Local I C 00.00 amps
008 Local 3I0 00.00 amps
009 Remote #1 I A 00.00 amps
010 Remote #1 I B 00.00 amps
011 Remote #1 I C 00.00 amps
012 Remote #1 3I0 00.00 amps
017 Remote Address 1 Tx Addr verified
077 R1 CDC 004.0 ms
076 R1 PingPong 004.0 ms
9300>
RFL 9300 RFL Electronics Inc.
January 30, 2002 6-51 (973) 334-3100
Figure 6-20. Typical UPDATE screen for a two-terminal system
001
002
005
006
007
008
009
010
011
012
013
014
015
016
017
018
076
101
9300>
Ping Pong #1
Ping Pong #2
Local I A
Local I B
Local I C
Local I 3I0
Remote #1 I A
Remote #1 I B
Remote #1 I C
Remote #1 I 3I0
Remote #2 I A
Remote #2 I B
Remote #2 I C
Remote #2 I 3I0
Remote Address 1
Remote Address 2
R1 PingPong
R2 PingPong
004.0 ms
004.0 ms
00.00 Amps
00.00 Amps
00.00 Amps
00.00 Amps
00.00 Amps
00.00 Amps
00.00 Amps
00.0 Amps
00.00 Amps
00.00 Amps
00.00 Amps
00.00 Amps
Tx Addr verified
Tx Addr verified
004.0 ms
004.0 ms
Value U
date - T
e ‘X<CR>‘ to Sto
Figure 6-21. Typical UPDATE screen for a three-terminal system
