Table 22-2. Replaceable parts, RFL 93 SHFI short haul fiber interface module
Assembly No. 107500
Circuit symbol
(Figs 22-4 & 22-5)
Description Part number
CAPACITORS
C3, 4, 10, 19, 21, 34, Capacitor, ceramic, 0.1uF, 10%, 50V 151-10104040603
36, 37, 41, 42, 45-52,
54-56
C7, 23 Capacitor, ceramic, 100pF, 5%, 50V 151-05101040503
C8, 24, 25 Capacitor, ceramic, 0.01uF, 10%, 50V 151-10103040603
C9, 20 Capacitor, ceramic, 0.047uF, 10%, 50V 151-10473040603
C13 Capacitor, ceramic, 820pF, 5%, 50V 151-10821050603
C17, 43 Capacitor, ceramic, 0.47uF, 10%, 50V 151-10474040612
C22, 35, 39, 44, 67 Capacitor, tantalum, 100uF, 10%, 10V 153-107070206
C38, 40 Capacitor, ceramic, 10uF, 10%, 10V 151-10106010607
RESISTORS
R1, 2 Resistor, thick film, 243Ω, 1%, 1/8W 700-15243034
R3, 12 Resistor, thick film, 4.75K, 1%, 1/8W 700-15475134
R6 Resistor, thick film, 162Ω, 1%, 1/8W 700-15162034
R7, 11, 13 Resistor, thick film, 60.4Ω, 1%, 1/4W 700-2060R435
R8 Resistor, thick film, 22.1Ω, 1%, 1/8W 700-1522R134
R10, 33, 37 Resistor, thick film, 10K, 1%, 1/8W 700-15100234
R14, 35 Resistor, thick film, 2.21K, 1%, 1/8W 700-15221134
R15 Resistor, thick film, 332Ω, 1%, 1/8W 700-15332034
R18 Resistor, thick film, 4.22K, 1%, 1/8W 700-15422134
R19 Resistor, thick film, 6.81K, 1%, 1/8W 700-15681134
R27, 28 Resistor, thick film, 4.7Ω, 1%, 1/8W 700-154R7034
R29 Resistor, thick film, 0.01Ω, 1%, 1W 700-40R01037
R30 Resistor, thick film, 10Ω, 1%, 1/8W 700-1510R034
R31 Resistor, thick film, 6.65K, 1%, 1/8W 700-15665134
R32 Resistor, thick film, 20Ω, 1%, 1/8W 700-1520R034
R34 Resistor, thick film, 2.43K, 1%, 1/8W 700-15243134
R36 Resistor, thick film, 124Ω, 1%, 1/8W 700-15124034
R38 Resistor, thick film, 0.56Ω, 1%, 1/4W 700-20R56034
R39 Resistor, thick film, 47.5Ω, 1%, 1/4W 700-2047R534
R42 Resistor, thick film, 0Ω, 1%, 1/8W 700-15000034
RZ1
Resistor network, 10K, 8R/PKG, SIP 95571
RFL 9300 RFL Electronics Inc.
October 20, 2004 22 - 6 (973) 334-3100
