Table 9-3 continued. Replaceable parts for oscillography board, used in RFL 9300 display module
Circuit Symbol
(Figs. 9-5 & 9-7)
Description Part Number
RESISTORS (continued)
RZ101, 102 Resistor network, 10K, 5R/PKG, SIP 32664
RZ103
Resistor network, 220Ω, 5R/PKG, SIP
99117
RZ104, 105 Resistor network, 10K, 8R/PKG, SIP 95571
RZ107 Resistor network, 1K, 5R/PKG, SIP 101439
RZ108
Resistor network, 680Ω, 7R/PKG, SIP
98448
RZ109 Resistor network, 6.8K, 9R/PKG, SIP 101776
SEMICONDUCTORS
CR101-110 Diode, silicon, 1N914B/1N4448 26482
Q101 Transistor, silicon, PNP, 2N3906 21565
Q102 Transistor, NPN, 40V, 2N4401 42574
U101-105 Opto device, photo isolator, 4N35 47104
U106, 113 IC, MOS, timer 0615 441
U107 IC, MOS,dual retriggerable, monostable multivibrator 0615 282
U108 IC, linear, quad, comparator 0620 241
U109 IC, MOS, PEEL call factory
U110, 123 IC, MOS, octal, buffer/driver 0615 381
U111 IC, linear, adjustable, precision, shunt regulator 0620 320
U112 IC, analog switch, quad, SPST, CMOS 0605 17
U114 IC, MOS quad, buffer/line driver 0615 292
U115 IC, peripheral, microprocessor, supervisor 0635 31
U116 IC, EPROM 8Kx8 0630 47
U117 IC, non-volatile SRAM, 8Kx8 0630 67
U118 IC, linear, voltage regulator, neg 5V 0620 210
U119 IC, A/D convertor, high speed 0625 35
U120 IC, MOS, hex inverter, schmitt trigger 0615 242
U121 IC, MOS, quad 2-input NOR gate 0615 160
U122 IC, MOS, octal, tri-state, D-flip-flop 0615 298
U124 IC, MOS, field programmable, gate array 0615 422
U125 IC, microprocessor, 8-bit 0640 36
MISCELLANEOUS COMPONENTS
DS101-104 Optoelectric device, red LED 99294
SP101 Audible warning device 30048
T101 Transformer 34199
TP101-105 Test point 98441 3
Y101 Crystal 30555
