RFL Electronics RFL 9300 - Table 19-2. Replaceable Parts, 50-Watt Power Supply Module for RFL 9300 Charge Comparison System

Table 19-2. Replaceable parts, 50-watt power supply module for RFL 9300 Charge Comparison System
RFL 48/125 Vdc (Assembly No. 106715-1)
Circuit Symbol
(Figs. 19-3 & 19-4)
Description Part Number
CAPACITORS
C1, 2 Capacitor, film, polypropylene, 0.22μF, 20%, 275V 1007 1808
C3, 4 Capacitor, ceramic disc, 0.01μF 1007 1788
C5 Capacitor, electrolytic, 680μF, 20%, 200V 1007 1813
C6 Capacitor, metalized polyester, 1.0μF, 10%, 250V 1007 1809
C7, 9, 25, 27, 35, 13, 46, Capacitor, ceramic, 1.0μF, 10%, 50V 0110 6
101, 108, 109, 110, 112,
114, 117-121
C8, 47 Capacitor, ceramic disc, 470pF, 10%, 1000V 1007 378
C11 Capacitor, ceramic, 0.0047μF, 10%, 50V 1007 1843
C12 Capacitor, ceramic, 0.022μF, 10%, 100V 1007 1840
C14 Capacitor, ceramic, 0.015μF, 10%, 100V 1007 1839
C15 Capacitor, ceramic, 0.047μF, 10%, 100V 1007 1842
C16, 103, 107, 10, 19, 20, 21 Capacitor, ceramic dip, 0.1μF, 10%, 50V 1007 1667
C18 Capacitor, ceramic dip, 0.033μF, 10%, 50V 1007 1453
C24, 26, 115, 116, 17 Capacitor, electrolytic, 220μF, 20%, 35V 1007 1817
C34, 111, 113 Capacitor, electrolytic, 2200μF, 20%, 10V 1007 1815
C39 Capacitor, suppressor, X2, 0.01μF, 20%, 250VAC 1007 1810
C49 Capacitor, ceramic, 0.1μF, 10%, 100V 0130 11041
C54, 55 Capacitor, ceramic disc, 470pF, 20%, 3KV 1007 1849
C102, 105, 106 Capacitor, ceramic dip, 0.01μF, 10%, 100V 1007 1390
C104 Capacitor, ceramic, 0.47μF, 10%, 50V 1007 1833
RESISTORS
R1 Resistor, carbon film, 330K, 5%, 1/2W 0500 6
R2 Resistor, metal film, axial, 1K, 1%, 1/2W 0410 2288
R3, 4 Resistor, fixed composition, 10Ω, 5%, 1/4W 1009 823
R5, 6 Resistor, wirewound, 0.10Ω,1%, 1W 1100 801
R7 Resistor, metal oxide, 10Ω, 5%, 2W 1510 2363
R8 Resistor, metal film, axial, 221K, 1%, 1/4W 0410 1513
R9, 19 Resistor, metal oxide, 100Ω, 5%, 2W 1510 2365
R10 Resistor, metal film, axial, 681Ω, 1%, 1/4W 0410 1272
R11, 13, 14, 16 Resistor, metal film, axial, 10K, 1%, 1/4W 0410 1384
R12 Resistor, metal film, axial, 4.22K, 1%, 1/4W 0410 1348
R15, 46, 104, 105, 106, 115, Resistor, metal film, axial, 1K, 1%, 1/4W 0410 1288
126, 127, 128, 129, 130
R17, 107 Resistor, metal film, axial, 100Ω, 1%, 1/4W 0410 1192
R18 Resistor, metal film, axial, 82.5Ω, 1%, 1/4W 0410 1184
R55 Resistor, fixed composition, 22Ω, 5%, 1/4W 1009 613
R101, 111 Resistor, metal film, axial, 274Ω, 1%, 1/4W 0410 1234
R102 Resistor, metal film, axial, 33.2Ω, 1%, 1/4W 0410 1146
R103 Resistor, metal film, axial, 3.65K, 1%, 1/4W 0410 1342
R108, 123 Resistor, metal oxide, 56Ω, 5%, 1W 1510 2371
R109 Resistor, metal film, axial, 475Ω, 1%, 1/4W 0410 1257
R110 Resistor, metal film, axial, 4.75K, 1%, 1/4W 0410 1353
R112
Resistor, metal film, axial, 100Ω, 1%, 1/2W
0410 2192
RFL 9300 RFL Electronics Inc.
May 5, 2002 19 - 4 (973) 334-3100
