Table 8-4. STARTUP mode parameters for RFL 9300 Two-Terminal Charge Comparison Systems
No. Display Definition
... Moving dots RFL 9300 is in STANDBY mode. Display controller parameter; not user-selectable.
0 EXIT Exit to STANDBY mode. Display function; can be set to either ENABLE or DISABLE.
1 PngPng 1 Value of ping-pong (round-trip delay) for remote 1.
3 SEQ TEST Phase Sequence Test.
4 DIFF CURR Differential Current Test
5 LOC IA Local Phase A current.
6 LOC IB Local Phase B current.
7 LOC IC Local Phase C current.
8 LOC 3I0 Local 3I0 current.
9 REM1 IA Remote 1 Phase A current.
111 EXIT Exit to STANDBY mode. Display function; can be set to either ENABLE or DISABLE.
Table 8-5. STARTUP mode parameters for RFL 300 Three-Terminal Charge Comparison Systems
No. Display Definition
... Moving dots RFL 9300 is in STANDBY mode. Display controller parameter; not user-selectable.
0 EXIT Exit to STANDBY mode. Display function; can be set to either ENABLE or DISABLE.
1 PngPng 1 Value of ping-pong (round-trip delay) for remote 1.
2 PngPng 2 Value of ping-pong (round-trip delay) for remote 2.
3 SEQ TEST Phase Sequence Test.
4 DIFF CURR Differential Current Test
5 LOC IA Local Phase A current.
6 LOC IB Local Phase B current.
7 LOC IC Local Phase C current.
8 LOC 3I0 Local 3I0 current.
9 REM1 IA Remote 1 Phase A current.
13 REM2 IA Remote 2 Phase A current.
111 EXIT Exit to STANDBY mode. Display function; can be set to either ENABLE or DISABLE.
