Table 8-2. Programmable parameters, RFL 9300 Three-Terminal Charge Comparison System
No. Display Definition Setting
20
PH BIAS Phase bias 3.0 A
21
GND BIAS Ground bias 1.5 A
22
BIAS CTL Bias control ENABLE *
23
GND DLY Ground delay DISABLE
24
DLAY SEC Bias control and ground delay time 1000 ms/30 s *
25
FD PHASE Local phase fault detector current 6 A
26
FD GND Local ground fault detector current 0.5 A
27
BACKUP System backup functions ENABLE
28
PH OC BU Phase overcurrent backup 31.875 A *
29
G OC BU Ground overcurrent backup 31 A *
30
PH TOC Phase inverse time-overcurrent enable/disable ENABLE
31
P PICKUP Phase inverse time-overcurrent pickup value 31.875A
32
PH CURVE Phase inverse time-overcurrent curve select USA1
33
PH DIAL Phase inverse time-overcurrent dial setting SET 15.0
34
GND TOC Ground inverse time-overcurrent enable/disable ENABLE
35
G PICKUP Ground inverse time-overcurrent pickup value 31.0A
36
G CURVE Ground inverse time-overcurrent curve select USA1
37
GND DIAL Ground inverse time-overcurrent dial setting SET 15.0
38
OVHD/UGD Overhead or underground cable UGD *
39
OPEN CON Open conductor action
ALARM
(6)
*
41
CM ALM D Communications alarm delay ENABLE *
43
DEFAULT Reset Parameter #'s 20 - 44 to default values
DISABLE
(2) *
44
BEEPER Enable/disable audible beeper
ENABLE
(3) *
45
DISPLAY Adjust display intensity
Brightest
(4) *
46
XMIT ADD1 Select transmit address 1 0000
47
XMIT ADD2 Select transmit address 2 0000
50
G B4 TRP Guard before trip ENABLE
51
RS232 BD Selects RS-232 baud rate 9600 *
52
RS232 PR Selects RS-232 handshaking protocol XON/XOFF *
141
SEL POLE Selective pole relaying enable/disable
DISABLE
(7)
145
TRIP RLS Selects trip release algorithm TRIP+100
Notes for Tables 8-1 and 8-2:
1. The asterisk (*) indicates factory default values.
2. When this parameter is enabled and the [ENT] key is pressed, the Display Controller requests that the PROGRAM mode security
code (.248) be entered. Once it is, all parameter values will be reset to the default values listed above. These are the values the pa-
rameters are set to before the RFL 9300 leaves the factory.
3. When this parameter is set to ENABLE, the audible beeper can be used to notify the operator if an alarm condition exists. During pro-
longed alarm conditions, the user may wish to disable the beeper until the condition is corrected. It is recommended that this parame-
ter remain enabled. Alarms may not be noticed if the display is in the READ or PROGRAM mode, or if the RFL 9300 is not being
manned and the user is depending on the beeper to indicate an alarm condition.
4. When this parameter is shown, the [8] and [0] keys can be used to increase or decrease the display intensity (or brightness). When
the setting is changed, the bottom line of the display will change to the new intensity, while the top line unit remains constant as a ref-
erence. When the [ENT] key is pressed, both lines assume the new intensity setting.
5. In dual-channel systems, either channel number may be displayed if COMM MODE (Parameter #49) is set to AUTO.
6. This parameter applies to three-pole systems only.
7. This parameter applies to single-pole systems only.
