Table 23-1. Replaceable parts, RFL 93 G.703 Interface I/O Module
(Assembly No. 106730)
Circuit Symbol
(Figs. 23-4 & 23-5)
Description Part Number
CAPACITORS
C1 Capacitor, ceramic dip, 0.0022μF, 5%, 50V 1007 1654
C2 Capacitor, ceramic, 560pF, 5%, 100V 0125 15615
C3 Capacitor, ceramic, 0.0056μF, 5%, 100V 0125 15625
C4 Capacitor, ceramic dip, 330pF, 10%, 100V 1007 1672
C5, 6, 8, 9, 10 Capacitor, ceramic dip, 0.01μF, 5%, 100V 1007 1645
C7 Capacitor, tantalum, 10μF, 10%, 20V 1007 1465
C11 Capacitor, electrolytic, 100μF, 20%, 25V 1007 1795
C12 Capacitor, electrolytic, 47μF, 20%, 35V 1007 1578
C13-27 Capacitor, ceramic dip, 0.1μF, 10%, 50V 0120 38
RESISTORS
R1 Resistor, metal film, axial, 487Ω, 1%, 1/4W 0410 1258
R2 Resistor, metal film, variable, 1K, 10%, 1/2W 49995
R3 Resistor, metal film, axial, 100K, 1%, 1/4W 0410 1480
R4, 16 Resistor, metal film, axial, 1K, 1%, 1/4W 0410 1288
R5 Resistor, metal film, axial, 78.7K, 1%, 1/4W 0410 1470
R6 Resistor, metal film, axial, 182K, 1%, 1/4W 0410 1505
R7 Resistor, metal film, axial, 8.45K, 1%, 1/4W 0410 1377
R8 Resistor, metal film, axial, 4.02K, 1%, 1/4W 0410 1346
R9 Resistor, metal film, variable, 2K, 10%, 1/2W 90392
R10 Resistor, metal film, axial, 681Ω, 1%, 1/4W 0410 1272
R11 Resistor, metal film, precision, 10Ω, 1%, 1/4W 1510 1015
R12 Resistor, metal film, axial, 2K, 1%, 1/4W 0410 1317
R13, 17, 19 Resistor, metal film, axial, 10K, 1%, 1/4W 0410 1384
R14 Resistor, fixed composition, 2.7Ω, 5%, 1/4W 1009 900
R15 Resistor, metal film, axial, 124Ω, 1%, 1/4W 0410 1201
R18 Resistor, metal film, axial, 49.9K, 1%, 1/4W 0410 1415
R20 Resistor, metal film, axial, 100Ω, 1%, 1/4W 0410 1192
RZ1
Resistor network, 10K, 8R/PKG, SIP
95571
RFL 9300 RFL Electronics Inc.
February 7, 2000 23 - 6 (973) 334-3100
