RFL Electronics RFL 9300 - Figure 6-15. Typical Configuration and Software Version Display for Two-Terminal and Three-Terminal Systems

6.5.6 VIEWING CONFIGURATION AND SOFTWARE INFORMATION
The "F" command tells the RFL 9300 to send a configuration and software version display to your terminal. This
display tells you how the RFL 9300 is configured, and what software version is being used in each of its control-
lers (communications controller(s), supervisor controller, phase controllers, and display controller).
Format: 9300>F [ENTER]
A typical configuration and software version display for two and three-terminal systems is shown in Figure 6-15.
# DESCRIPTION CONFIGURATION
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
130 Terminals 2
132 CT Full Scale 5 amps
133 Frequency 60 Hz
140 Single Pole Active
# MODULE SOFTWARE VERSION
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
103 SW ID CC 009
104 SW ID CC2 009*
105 SW ID SV 007
106 SW ID PCA 009
107 SW ID PCB 009
108 SW ID PCC 009
109 SW ID PCG 009
110 SW ID DC 009
9300> _
*For a two-terminal system, the second communications module
(CC2) is not installed and the software version for parameter
#104 will indicate “Not Installed”
Figure 6-15. Typical configuration and software version display for two-terminal and three-terminal systems
The configuration and software version display shows the code number for each item, a brief description of its
meaning, and its value. Full descriptions for each item are as follows:
130 - Terminals The RFL 9300's terminal configuration; "2" for two-terminal, or "3" for three-terminal.
132 - CT Full Scale The rating of the CT's being used to feed the RFL 9300; "1" for 1-amp CT's, or "5" for 5-amp
CT's.
133 - Frequency The power system frequency; either 50 Hz or 60 Hz.
140 – Single Pole Single Pole mode; either active or inactive.
103 - SW ID CC1 The software version currently running on Communications Controller #1.
104 - SW ID CC2 The software version currently running on Communications Controller #2. If there is only one
Communications Controller in the RFL 9300, the words "Not installed" will appear.
105 - SW ID SV The software version currently running on the Supervisor Controller.
106 - SW ID PCA The software version currently running on the Phase Controller Module monitoring Phase A.
107 - SW ID PCB The software version currently running on the Phase Controller Module monitoring Phase B.
108 - SW ID PCC The software version currently running on the Phase Controller Module monitoring Phase C.
109 - SW ID PCG The software version currently running on the Phase Controller Module monitoring 3I
0
.
110 - SW ID DC The software version currently running on the Display Controller.
