Table 18-2. Replaceable parts, RFL 93 FT/FR I/O-8M Singlewidth fiber optic I/O module
(Assembly No. 105850)
Circuit symbol
(Figs 18-8 & 18-9)
Description Part number
CAPACITORS
C1, 2, 3, 4, 13, 14, 15,
Capacitor, ceramic, 0.1
μF, 20%, 50V
1007 1366
23, 24, 29, 30
C5, 40 Capacitor, ceramic, 10 pF, 10%, 200V 0125 21001
C6
Capacitor, ceramic dipped, 0.47
μF, 20%, 50V
1007 1560
C7, 33, 34, 36, 37, 48
Capacitor, ceramic dipped, 0.01
μF, 5%, 100V
1007 1645
C8, 10, 11, 16, 17,
Capacitor, tantalum, 1
μF, 10%, 35V
1007 1768
43, 44
C9
Capacitor, electrolytic, 100
μF, 20%, 25V
1007 1630
C12
Capacitor, tantalum, 22
μF, 20%, 16V
1007 1569
C18, 19, 20, 21 Capacitor, ceramic dipped, 470 pF, 10%, 100V 1007 1392
C22 Capacitor, ceramic disc, 220 pF, 10%, 500V 1007 493
C25
Capacitor, ceramic dipped, 0.001
μF, 10%, 50V
1007 1666
C26
Capacitor, ceramic dipped, 0.0039
μF, 5%, 50V
1007 1657
C27, 28, 32, 52
Capacitor, ceramic disc, 0.01
μF, 20%, 500V
1007 83
C51 Capacitor, ceramic, 15 pF 0125 21505
RESISTORS
R1, 10
Resistor, metal film, precision, 449
Ω, 1%, 1/4W
0410 1259
R2 Resistor, metal film, precision, 4.99K, 1%, 1/4W 0410 1355
R3, 29
Resistor, metal film, precision, 100
Ω, 1%, 1/4W
0410 1192
R4, 5 Resistor, metal film, precision, 3.57K, 1%, 1/4W 0410 1341
R6, 8, 15, 17, 22, 32, Resistor, metal film, precision, 1K, 1%, 1/4W 0410 1288
33, 36, 37
R7 Resistor, metal film, precision, 301K, 1%, 1/4W 0410 1526
R9
Resistor, metal film, precision, 12.1
Ω, 1%, 1/2W
1510 2109
R11 Resistor, metal film, precision, 2.49K, 1%, 1/4W 0410 1326
R12, 16, 28 Resistor, metal film, precision, 100K, 1%, 1/4W 0410 1480
R13 Resistor, metal film, precision, 2K, 1%, 1/4W 0410 1317
R14 Resistor, metal film, precision, 20K, 1%, 1/4W 0410 1413
R18 Resistor, metal film, precision, 100K, 1%, 1/4W 0410 1480
R19 Resistor, metal film, precision, 3.01K, 1%, 1/4W 0410 1334
R20 Resistor, metal film, precision, 4.32K, 1%, 1/4W 0410 1349
R21
Resistor, metal film, precision, 511
Ω, 1%, 1/2W
0410 2260
R23, 24, 25, 34 Resistor, metal film, precision, 499K, 1%, 1/4W 0410 1547
